AMC16MA AC multi circuit energy meter

AMC16MA AC multi circuit energy meter is a measuring device designed specifically for the power supply management of server in the data center. Such device is small and exquisite in design, capable of centralized monitoring on electric parameters and on-off states of dozens of circuits, including incoming line circuit and outgoing line circuit, and it achieves the highly integration of monitoring circuits in volume.

GET A QUOTE CONTACT US

Fast And Safe Logistics
Sample Available

AMC16MA CE-AMC16MA LVD-AMC16Z-ZA EMC-AMC16Z-ZA

AMC16MA

RS485 communication interface

Designed specifically for the power supply management of server in the data center

Including 2 incoming line circuit and 36 outgoing line circuit

U, I, P, Q, S, PF, kWh, kvarh

Optional 2nd-15th harmonic

Functional features

Three-phase 2 channels inlet voltage, current, active power, reactive power, power factor, active energy, reactive energy

Single-phase 36 channels outlet (Three-phase 12 channels outlet) voltage, current, active power, reactive power, power factor, active energy, reactive energy

1 on-off output

2 RS485 communication

Optional 2nd-15th harmonic

Parameters

Distribution system	AC
Measurement	Three-phase 2 channels inlet voltage, current, active power, reactive power, power factor, active energy, reactive energy
Busbar voltage	Rated	220V AC
	Measurement range	40-400V AC
	Overload	instantaneous voltage twice/30 seconds
Current	Inlet	CT	XXA/5A
		Range	0-10A
	Outlet	CT	100A/20mA
		Range	0-120A
	Overload	1.2 times for continuous,and 10 times/5 seconds for instantaneous
Accuracy	Inlet	Class 1.0
	Outlet	Class 2.0
Frequency	45-60Hz
Power supply	AC85-265V/DC100V-350V
Insulation resistance	100MΩ
Communication	Modbus-RTU
