| Downstream | RS485 communication | |||
| Uplink | 4G communication | NB-IoT communication | 2G communication | LoRa communication |
| SIM Card Voltage | 3V，1.8V | / | ||
| Antenna Interface | 50Ω/SMA(Female head) | |||
| Serial Port Type | RS-485 | |||
| Baud Rate | 4800bps、9600bps、19200bps、38400bps(default 9600bps) | |||
| Working Voltage | DC24V or AC/DC220V① | |||
| Working Temperature | -10℃～55℃ | |||
| Storage Temperature | -20℃～70℃ | |||
| Humidity Range | 0 to 95% non-condensing | |||
| Note: ①AC/DC220V power supply requires an external AWT100 power module. | ||||
AWT100-4G Wireless Converter Communication Terminal
AWT100 converter communication terminal is a new wireless data acquisition device launched by Acrel. The uplink communication includes 2G, 4G, NB, LoRa, LoRaWAN and other communication modes. The downlink interface provides a standard RS485 data interface, which can easily connect power meters and RTUs, PLC, industrial computers and other equipment, only need to complete the initial configuration, you can complete the data acquisition of MODBUS equipment; at the same time AWT100 series wireless communication terminal uses a powerful micro-processing chip, with built-in watchdog technology, reliable performance stable.
